Tok i go pas
Male Haidrolik Hos Fitting bilong mipela i kamap long givim ol gutpela, lik-prup koneksen long askim long ol haidrolik aplikesen. Dispela fiting i bin kamap wantaim stretpela treding na ol samting i save stap longpela taim, na dispela i mekim na ol i ken mekim gut wok long ol indastriel, mobail, na solwara haidrolik sistem.
Ol spesifik
|
PAT NO. |
TRAIM E |
EM I BORE |
OL DIIMENSEN |
||||
|
DN |
DES |
A |
C |
H |
S2 |
||
|
20141-10-03 |
M10X1 |
5 |
03 |
41.1 |
2.5 |
20.7 |
14 |
|
20141-10-04 |
M10X1 |
6 |
04 |
43.2 |
2.5 |
21.5 |
14 |
|
20141-12-03 |
M12X1.5 |
5 |
03 |
40.9 |
4 |
21.2 |
17 |
|
20141-12-04 |
M12X1.5 |
6 |
04 |
43 |
4 |
22 |
17 |
|
20141-14-04 |
M14X1.5 |
6 |
04 |
43.4 |
4.5 |
21.3 |
19 |
|
20141-14-05 |
M14X1.5 |
8 |
05 |
45.5 |
4.5 |
22.2 |
19 |
|
20141-16-04 |
M16X1.5 |
6 |
04 |
43.7 |
4.5 |
21.4 |
22 |
|
20141-16-05 |
M16X1.5 |
8 |
05 |
45.8 |
4.5 |
22.5 |
22 |
|
20141-16-06 |
M16X1.5 |
10 |
06 |
47.4 |
4.5 |
24.1 |
22 |
|
20141-18-05T |
M18X1.5 |
8 |
05 |
46.8 |
4 |
22.6 |
24 |
|
20141-18-06 |
M18X1.5 |
10 |
06 |
48.5 |
4 |
24.2 |
24 |
|
20141-18-08 |
M18X1.5 |
12 |
08 |
52.2 |
4 |
25.7 |
24 |
|
20141-20-06T |
M20X1.5 |
10 |
06 |
48.2 |
5.5 |
23.9 |
27 |
|
20141-20-08 |
M20X1.5 |
12 |
08 |
62.1 |
5.5 |
27.2 |
27 |
|
20141-22-06T |
M22X1.5 |
10 |
06 |
58.4 |
5 |
25.7 |
27 |
|
20141-22-08 |
M22X1.5 |
12 |
08 |
62.1 |
5 |
27.2 |
27 |
|
20141-24-08T |
M24X1.5 |
12 |
08 |
61.1 |
5.5 |
26.1 |
30 |
|
20141-24-10 |
M24X1.5 |
16 |
10 |
75.4 |
5 |
29.6 |
30 |
|
20141-27-10DT |
M27X1.5 |
16 |
10 |
74.4 |
5.5 |
29.6 |
32 |
|
20141-27-10T |
M27X2 |
16 |
10 |
74.4 |
5.5 |
29.6 |
32 |
|
20141-30-12D |
M30X1.5 |
20 |
12 |
80.9 |
6 |
33.5 |
36 |
|
20141-30-12 |
M30X2 |
20 |
12 |
80.9 |
6 |
33.5 |
36 |
|
20141-36-14T |
M36X2 |
22 |
14 |
83 |
7 |
32.64 |
41 |
|
20141-39-16T |
M39X2 |
25 |
16 |
88.2 |
7 |
33.95 |
46 |
|
20141-45-20T |
M45X2 |
32 |
20 |
99.1 |
8.5 |
38.4 |
55 |
|
20141-52-24T |
M52X2 |
40 |
24 |
114.1 |
9 |
43.4 |
60 |
Ol parameta/Teknikol Data
|
Orijinel |
ZheJiang, Saina |
Deit deit |
yu ken toktok long en |
|
Setifikesen |
GB/T19001-2016 idt ISO9001:2015 |
Peking |
ekspotim standet |
|
Meteriel |
Sil bilong Kabon |
Woranti |
1 yia |
|
Pemen tem |
TT |
MOQ |
2000 |
|
Kondisen |
Nupela |
Kala |
Waitpela zinc, kala zinc |
Long Kampani
Ol gutpela samting
Bilong wanem ol Profesenel i makim ol Fitting Bilong Mipela:
40% longpela sevis laip winim indastri averes
72-aua imejensi prodaksen sevis
Ol aplikesen enjinia we oli givim long evri bigfala akaon we oli givim.
Ril-}taim inventori visibiliti tru long kastoma portal
FAQ
K: Wanem nao wan Man we i stap long Haedrolik Hos Fitting?
A: Wanpela man bilong haidrolik hos i fit em i wanpela kain konekta ol i wokim bilong pasim ol haidrolik hos long ol komponen (olsem, ol pam, ol valv, ol silinda). Em i gat ol tret bilong ausait we i skruim wanpela meri i kam insait long wanpela port o adapta i stret wantaim.
Q: Wanem nao ol komon kaen blong ol man haedrolik fiting?
A: Ol kain kain kain em:
JIC (Join Indastri Kaunsil): 37-digri flared sia.
NPT (Nesenel Paip i Taper): Ol tred we oli tapered blong silim.
BSP (Paipim bilong ol Briten): Ol tret i no stret o i go daun (BSP/BSPT).
ORFS (O-Ring Pes Sil): Flet pes wantaim O-ring bilong lik-Pruf koneksen.
Metric: Ol Tred i bihainim ISO/ DIN standet.
Q: Olsem wanem mi ken makim stretpela man haidrolik fiting?
A: Tingim:
Tread taep/saes (eg, 1/2" NPT, JIC #8).
Presa reiting (match i go long ol samting bilong sistem).
Ol samting (stiel, steinles stiel, bras).
Kompatibiliti wantaim ol hos na ol ikwipmen.
Q: Olsem wanem mi ken stopim ol lik long ol haidrolik fiting bilong ol man?
A: Ol tred we oli sua oli klin mo oli no spolem.
Yusim thread silant (long NPT) o O-ring (long ORFS).
Tait long tok ol i rekomendim-ivoid antap long-}taiting.
Q: Mi ken miksim ol narapela narapela tret standet (olsem, NPT wantaim BSP)?
A: No. Ol thread we oli Miksim i save mekem ol lik o damej. Yusum ol adapta sapos yu konektem ol standet we oli no sem mak.
Q: Wanem samting i narapela kain long NPT na NPTF tred?
A: NPT (Nesenel Paip Taper): I nidim silan.
NPTF (Dryseal): Ol i wokim bilong pasim nating tasol ol i no save pasim, tasol ol i save yusim planti taim bilong lukautim gut.
Q: Olsem wanem mi ken skelim sais bilong tred bilong wanpela man haidrolik fiting?
A: Yusum wan kalipa blong mesarem aotsaed diamita (OD) blong ol tred mo lukluk long wan tred jat. Toksave long pitch (ol threads long wan wan ins bilong imperial, mm bilong metric).
K: Wanem ol samting ol man bilong haidrolik i save putim long ol samting bilong haidrolik ol i wokim?
A: stiel bilong Kabon: Kost-i wok strong, bikpela strong.
Steinless stiel: Korosen-}we i no inap.
Bras: Ol i yusim long liklik mak bilong-}presa, ol envairomen i save bagarapim ol samting.
Q: Wanem nao maksimum presa reiting blong ol fiting blong ol man?
A: Ol senis long taip/materiel (olsem, ol JIC fiting i ken lukautim 5,000+ PSI). Sekim ol spesifikasen bilong ol kampani i wokim.
K: Mi ken yusim gen ol man bilong haidrolik?
A: Yes, sapos i no bagarap. Sekim ol tred na ol mak bilong pasim bilong wear/krack pastaim long yusim gen.
K: Bilong wanem man bilong mi i save lus oltaim?
A: Vaibresen: Yusim lok bilong lok o tret-lokim wara.
Tok i no stret: Bihainim ol samting bilong wokim ol samting.
Yu mas werim: Riples sapos yu rausim klos.
Q: Mi ken baim ol hai- kwaliti bilong man haidrolik fiting we?
A: Baim long ol setifiket haidrolik saplaia o ol kampani i wokim. Mekem sua se yu folem ol standet (SAE, ISO, DIN).
